Matriz de Punto
  • T2540-9

    • Print Speeds over 500 cps
    • USB & Parallel Standard
    • Optional Integrated Ethernet
    • Tractor Feed and Manual Insertion

  • Especificações
  • Aplicações
  • Transferências
  • T2540-9

    Print Speed 9 wire printhead: At 10, 12 cpi; HS Draft: 533, 519 cps; Draft: 400, 376 cps; NLQ: 100, 100 cps
    24 wire printhead: At 10, 12 cpi: HS Draft: 480, 576 cps; Draft: 400, 480 cps; LQ: 133, 160 cps
    Print Method Serial Impact
    Resolution 9 pin: Up to 144 x 240 dpi; 24 pin: Up to 360 x 360 dpi
    Throughput 395 pages per hour (ECMA 132)
    Character Density 10, 12, 15 (half height), 15 (full height), 17.1, 20 cpi
    Line Density 1, 2, 3, 4, 6, 8, 12 lpi
    Printhead Life 400 M strokes per pin
    Memory 256Kb
    Standard Connectivity Parallel (Bi-directional), USB 2.0
    Optional Connectivity Internal Ethernet 10/100baseT, Serial RS232
    Standard Emulation 9 pin: IBM® Proprinter XL, Epson® ESC/P, Oki® Superset Commands
    24 pin: IBM® Proprinter XL24E, Epson® ESC/P2
    Fonts 9 pin: HS Draft, Draft, Courier, Quadrato, OCR-B, OCR-A
    24 pin: HS Draft, Draft, Roman, Sans Serif, Prestige,Script, Orator, Gothic, Souvenir, OCR-B, OCR-A
    10 barcodes for 9 + 24 pin machines
    Consumables Black Ribbon: 8 million characters
    Standard Paper Handling Push or Pull tractor, friction for cut sheet
    Number of Copies 1 + 5 copies (9 pin)
    1 + 4 copies (24 pin)
    Form Thickness Max. 0.35mm
    Paper Type Continuous and Cut Forms
    Paper Size 3-10 inches wide
    Physical Weight 18.73 lbs.
    Physical Size (WxDxH): 21.3 X 13 X 5.3 inches
    Power Voltage 120 V
    Power Consumption 51 Watts printing, max. 7 Watts in sleep mode
    Workload Up to 20,000 pages per month
    Reliability MTBF 15,000 hours
    Drivers Windows 9x/ME, 2000, 2003 Server, XP, Vista
    Temperature +10°C to +40°C
    Humidity 10% to 85% relative (non-condensing)
    Acoustic Less than 52dB(A) Quiet mode
    Warranty One Year return to depot
    Note For OCR applications it is recommended that your readers are tested with print samples supplied by DASCOM prior to purchase. Paper is a highly variable medium and should be tested prior to purchase. The quoted consumable life is the average for the printer when used under normal operating conditions.
